    ASTM B333 Hastelloy B3 Alloy Steel Plate 0.5-10MM

    Ask Lasest Price
    Brand Name : Mittel
    Model Number : Hastelloy B3
    Certification : SGS ISO MTC
    Price : 4.85 USD/KG
    Payment Terms : L/C, T/T
    Supply Ability : 80000KGS
    Delivery Time : 7 Working Days
    • Product Details
    • Company Profile

    ASTM B333 Hastelloy B3 Alloy Steel Plate 0.5-10MM

    Hastelloy B3 Plate ASTM B333 Hastelloy B3 Alloy Steel Plate 0.5-10MM


    Hastelloy B3 Plate Grade and Specification
    StandardASTM,AISI, AMS,MLS,EN,JIS,DIN,GOSTASTM / ASME SB 162 UNS 2200 (NICKEL 200) / UNS 2201 (NICKEL 201 ASTM / ASME SB 127UNS 4400 (MONEL 400) ASTM / ASME SB 424 UNS 8825 (INCONEL 825) ASTM / ASME SB 168 UNS 6600 (INCONEL 600) / UNS 6601 (INCONEL 601) ASTM / ASME SB 443 UNS 6625 (INCONEL 625) ASTM / ASME SB 574 UNS 10276 (HASTELLOY C 276) ASTM / ASME SB 462 UNS 8020 (ALLOY 20 / 20 CB 3)
    Thickness1.2-100mm
    Width1000-1500mm
    Length1000-6000mm
    Surface2B, No.3, No.4, HL, BA, 8K
    Manufacturing processHot rolled, cold rolled
    Grades AvailableA330 Plate,Alloy 20 Plate, Alloy 400 Plate, Alloy 625 Plate, Alloy 825 Plate, Hastelloy B-2 Plate, Hastelloy B-3 Plate. Hastelloy C-22 Plate, Hastelloy C-276 Plate, Hastelloy X Plate, Incoloy 800 Plate, Incoloy 825 Plate, Inconel 600 Plate, Inconel 601 Plate, Inconel 617 Plate, Inconel 622 Plate, Inconel 625 plate, Inconel 690 Plate, Inconel 718 Plate, Inconel 800 Plate, Monel 400 Plate, Monel K500 Plate, Nickel 200 Plate, Nickel 201 Plate, Nicrofer 59 Plate
    Packingbubble bag and plywood pallet or according to the customers’ requirements.
    Export To:Saudi arabia, Kuwait, Qatar, Oman, Yemen, UAE, Iran, Turkey, Kazakhstan, Greece, Singapore, Thailand, Indonesia, Veitnam, South Africa,South America,Brazil, India, Australia, Egypt.

    Hastelloy B3 Plate Properties
    Chemical Properties Of Hastelloy B2 Plate
    Ni
    Mo
    Fe
    C
    Co
    Cr
    Mn
    Si
    65.0 min
    28.5
    1.5
    .01 max
    3.0 max
    1.5
    3.0 max
    .10 max
    Ti
    W
    Al
    Cu
    .2 max
    3.0 max
    .50 max
    .20 max

    Mechanical Properties Of Hastelloy B2 Plate
    Temperature,°F702004006008001000
    Ultimate Tensile Strength, ksi125.0120.7110.0104.4102.097.8
    0.2% Yield Strength, ksi60.655.347.043.542.439.0
    Elongation, %53.456.959.763.462.059.0

    Physical Properties Of Hastelloy B2 Plate
    Temperature,°F
    200
    400
    600
    800
    1000
    1200
    1400
    1600
    Coefficient* of Thermal Expansion, in/in°F x 10-6
    5.7
    6.1
    6.3
    6.5
    6.6
    6.5
    7.1
    7.6
    Modulus of Elasticity Dynamic, psi x 10-6
    30.9
    30.1
    29.3
    28.3
    27.2
    26.5
    24.9
    23.3

    ASTM B333 Hastelloy B3 Alloy Steel Plate 0.5-10MMASTM B333 Hastelloy B3 Alloy Steel Plate 0.5-10MMASTM B333 Hastelloy B3 Alloy Steel Plate 0.5-10MM
